Hotronix® 360 IQ® Hat Heat Press

The 360 IQ features Hotronix IQ technology that lets you track productivity and program the machine for specific jobs, plus independently controlled heated upper and lower platens so you can print the front, back, and sides of a cap without removing or repositioning it.

The patented Dual Silicone Platen has an elliptical design that adapts to the logo's thickness and shape to give equal pressure over the entire cap, guaranteeing adhesion with no lines, marks, or scorching.

Yes, the 360 IQ lets you print many types and sizes of hats with just one platen.

The 360 IQ works with patches, transfers, emblems, FlexStyle logos, leather patches, and 3D embroidery designs.

The press includes 3 foam cover pads of different thicknesses for applying thick or dimensional items.

The recommended top heater temperature is 280F/138C and bottom heater temperature is 320F/160C, with a recommended maximum print area of about 2.25 in height by 5.5 in width (absolute max 2.5 in x 5.75 in).

The 360 IQ requires 120V, 10 amps, 800W or 240V, 5 amps, 800W, with a designated circuit breaker.

It includes a lifetime warranty on the heating element, 5 years on the framework, 2 years on the circuit board, and 1 year on parts and labor.
